Technical Textiles And Their Applications
Packaging textiles

Technical Textiles And Their Applications

Written by: O.L. Shanmugasundaram

Today it's needed to adopt a different approach to textiles;fabrics have to be regarded not only just as a surface, to be interpretedgraphically, but as a material to all intents and purposes, with its ownintrinsic structure and performance. In the sector of technical textiles thereare a large number of niches and products.


Textiles are everywhere in modern society; worn asprotection and self expression on the human body, used as decoration andcomfort elements in homes, offices, hospitals, hotels or public buildings, asinterior components in cars, buses, trains, ships and airplanes, or structuralelements for tents, roofs, bridges, or as reinforcements for roads, and dikesbut also as bags, nets or artificial turf in sports and outdoor activities. Inspite of the fact that normally the textile industry is considered atraditional sector, today it has become one of the main test-beds regardingnew business strategies. The new market standards, achievable with processinnovations, which on one hand reduce costs, whereas on the other hand allowsto distinguish oneself from the other competitors, have become a very importantcompetitive factor. Ever since the mid 80's, the market of textile productsstarted to change radically, and it was divided between: standard productions,identified with a low innovation and technology level, medium to low quality,weak customer service - complex productions identified with a high productinnovation level, with the use of state-of-the art process technologies and productresearch, a strong aesthetic element, as well as certain and high qualitylevels, quick timing addressing requirements, production flexibility andcustomer service. As well as the above, currently there is a new phase in thetextile field in which new materials allow to make dynamic and interactiveproducts, able to offer protection, comfort and performance. The textilematerials are therefore becoming the basis for a completely new range of newapplications.


Innovative and Technical Textiles: A Sector of Niches withHigh Added Value


Today it's needed to adopt a different approach to textiles;fabrics have to be regarded not only just as a surface, to be interpretedgraphically, but as a material to all intents and purposes, with its ownintrinsic structure and performance. In the sector of technical textiles thereare a large number of niches and products, often highly technological and wherethe end user requires specific requirements, and for which the cost is nolonger the only parameter taken into consideration. Regarding innovativetextiles the market is growing rapidly and many developments of new productsand applications are underway. The technological evolution which transversallyintegrates human science, materials and information technology, does allow to foreseepositive perspectives in the approach towards development of new products andapplications.


The general trend is therefore towards high tech, highperformance fabrics designed not just to look attractive, but to offer asignificant added value in terms of functionality.


Application Field of Technical Textiles



In the field of specialized applications, the technological assets are those that provide the highest performance and comfort standards, and ensure a better quality of life. Already there are fabrics capable of reducing risks (e.g. antibacterial, mite-proof, insect proof, odorless, flame retardant, soil-resistant, anti-UV and anti-electromagnetic radiation, etc.). Other fabrics function actively (e.g. heat-regulating, with new visual features, or providing cosmetic-medical effects, and so forth).


Home Textiles


Traditionally textiles have been an important part of theinterior of human habitations, as well as human transportation systems such ascars, buses, passenger trains, cruise ships or airplanes. In that respecttextile served three basic purposes:


  • Decoration (carpets, wall coverings, curtains & drapes, table cloths, etc.)
  • Comfort (Upholstery, seat covers, mattresses, bed sheets, blankets, carpets etc)
  • Safety (Safety belts and nets, airbags)


While the basic functions remain unchanged, increased userand regulatory requirements for textile interiors have already made suchproducts more complex, multifunctional or even "intelligent".




Functionality

Application

Stain or water repellence

Table cloth, curtains, furniture, car, bus, train. Airplane seats

Flame retardance

All possible textile interiors of buildings and transport systems

Anti-static behaviour

Upholestery and seat covers

Anti-bacterial behaviour

Bedding, medical textiles

UV- protection

Roofs, tents, awnings, blinds, curtains

Insect repellance

Tents, nets

Odour absorption

Bedding, furniture, car, bus, train, airplane seats



Textile Structures for building


Textiles have in the past been predominantly confined to the interior decoration; they are now increasingly becoming part of these constructions themselves. Thanks to better performance characteristics in terms of their strength-weight ratio, durability, flexibility, insulating and absorption properties, and fire and heat resistance, they are in a position to replace more traditional construction materials such as steel and other metals, wood and plastics. Examples of such innovative uses of textiles include:


  • Textile-reinforced concrete
  • Fibre- and textile-based bridging cables and elements
  • Erosion and landslide protection systems
  • Textile reinforcement of dykes and other water management systems
  • Fibre-based light, flexible and durable piping and canalization


Clothing


The skin is the principal element that separates and protects the human body from the environment around it. It is also acts as a major exchange system of energy (e.g. heat) and matter (fluids and gases such as water, oxygen etc.) between body and environment. Clothing as an artificial second skin has always been used by humans to enhance the protective function of their own skin. However such additional protection often has a negative effect upon the exchange functionality of the human skin, in certain cases very severely like in the case of full body armour, fire-fighters, uniforms or diving suits. Functional and smart or intelligent clothing are the innovative response to such limitations. Functional clothing refers to products in which one or several specific functionalities are emphasised like strong insulation, water or fire resistance, breathability, wear resistance etc. Smart clothing takes (multi)functionality one step further as it refers to products that can offer their functions in a more adaptive way in response to stimuli from the environment or the wearer. Smart garments can for instance:


  • adapt their insulation function according to temperature
  • changes,
  • detect vital signals of the wearer's body
  • change colour or emit light upon defined stimuli
  • generate or accumulate electric energy to power medical and other electronic devices


Protection


The term 'protective clothing' covers garments and accessories intended to protect people against the elements, dangerous or hazardous materials, processes or events during the course of their work or during leisure activities. It also encompasses garments intended to protect products, the workplace or environment against people (as for clean room garments), Demand for protective clothing is affected not only by increased levels of industrialization but also by an increased awareness of, Health & Safety and hygiene legislation. The rising trend in violent crime, combined with increased military operations, have led to increases in public spending aimed at reducing injuries to police, civil defence, and the military.




The main end use segments include


Particulate protection (clean room)

Chemical protection

Flame retardant

Cut resistant

Outdoor protection, hi-visibility


Manufacturers of protective clothing are also realizing the need to supply workers with comfortable garments. In fact although guaranteed high levels of performance wiII remain critical for protective garments, increased emphasis is being placed on wearer comfort, and design aesthetics.


Sport


Increasing worldwide interest and participation in active sports and outdoor leisure pursuits have resulted in strong historical growth in the consumption of textile materials in sporting and related goods and equipment.


The continuing pursuit of even higher standards of end-user safety and performance is now stimulating the use of higher priced, branded speciality fibres and other materials, Applications of textiles for sport and leisure are extremely diverse, ranging from sportswear to boat covers, tents or high performance composite


Medical Textiles


Textile products are omnipresent in the field of human hygiene and medical practice. Their use is based on a number of typical basic textile properties like softness and lightness, flexibility, absorption, filtering etc. Traditional applications include wound care products, diapers, braces, protheses and orthoses, wipes, breathing masks, bedding and covers, ropes and belts etc.


Innovative textile products can both add significantly to effectiveness of medical treatments as well as patient comfort At the same time, new medical textiles, may contribute to cost containment. Such innovative products:


  • Provide new treatment options (textile based implants instead of scarce donor organs; artificial tissues, joints and ligaments),
  • Speed up recovery after medical treatment (innovative wound dressings; light, Breathable orthoses/ protheses)
  • Enhance quality of life of chronically ill people (functional clothing)


Textiles for Transports


The idea of using textiles to transport humans or goods is not recent. Textile ropes and sails have been instrumental in powering ships since the early days of human civilization and the birth of human aviation in the form of balloons, zeppelins and early airplane prototypes is equally textile linked.


The modern concept of mobility enabling textiles come in the form of:


  • performance fibre-based textiles used in balloons, parachutes, sails, nets and ropes;
  • aircraft wing and body structures or boat rumps made of fibre and textile-based composites;
  • inflatable components of satellites or other spacecraft;
  • flexible reservoirs, containers or bags used for transportation of gases, liquids and bulk goods by road, rail, water or air.
  • composites are underway or expected in the near future across all transportation system fields.


Industrial Textiles


Technical textiles keep the wheels of industry turning in many different ways, separating and purifying industrial products, cleaning gases and effluents, transporting materials between processes, carrying them through and turning machines, absorbing dirt and oil, and acting as substrates for abrasive sheets and other coated products. Industry is an extremely diverse application sector in terms of products, functions and enduses ranging from lightweight nonwoven filters, knitted nets and brushes to heavyweight coated conveyor belting.



Filtration and cleaning products are the most important product segments;


Agrotextiles


Applications for technical textiles in agriculture include all activities concerned with the growing and harvesting of crops and animals. The principal function of most agricultural textiles relates to the protection of either food produce, animals or land. Enduses range from crop production, through forestry and horticulture, to animal and poultry rearing and fishing. The fishing segment is a large consumer of textile materials. Fishing methods are becoming more industrialized, replacing older small net and line fishing techniques.


Geotextiles


Geotextiles are defined as all woven, nonwoven and knitted textile materials used mainly by the civil engineering industry to provide a range of functions such as support, drainage and separation at or below ground level. Geotextiles are used in a wide range of applications including the construction of buildings, bridges, dams, roads, railways and paths as well as embankments, cuttings, dykes and sub-sea coastal engineering projects.


These are now being increasingly widely used for waste containment in hazardous waste tips as well as for industrial and municipal effluent treatment facilities.


Conclusion


At present some 60% of all the textile products made world wide employ fibers that were not yet being marketed just fifty-sixty years ago, and there are estimates that 30% of the products sold fifty years tram now have not even been invented yet. The fabrics of the future will be entirely re-conceptualized; researchers all over the world have been quizzed about the products that will be appearing on the market aver the coming decades, and their belief is that there will be materials capable of repairing themselves when damaged, fabrics with built-in digital devices, smart textiles with nano materials and much, much more. With textiles it will be possible offer innovative solutions for global problems, such as pollution, health issues, transports, protection, communication, and so on.


About the Author


The author is Lecturer in Department of Textile Technology at KSR College of Technology, Tiruchengode, Tamilnadu.
